| Price scales | Quantity | Price per unit |
|---|---|---|
| Prices excluding VAT and shipping costs | 1-4 | CHF 695.50 |
| 5-19 | CHF 555.20 | |
| 20-49 | CHF 457.50 | |
| from 50 | On request |
NRND (Not Recommended for New Designs): These products continue to be available, but are not recommended for new projects. Our sales team will be happy to suggest alternatives.
Specifications
| Values at nominal voltage | |
| Nominal voltage | 24 V |
| No load speed | 10300 rpm |
| No load current | 443 mA |
| Nominal speed | 9120 rpm |
| Nominal torque (max. continuous torque) | 124 mNm |
| Nominal current (max. continuous current) | 5.97 A |
| Stall torque | 1210 mNm |
| Stall current | 55 A |
| Max. efficiency | 83 % |
| Characteristics | |
| Terminal resistance | 0.436 Ω |
| Terminal inductance | 0.106 mH |
| Torque constant | 22.1 mNm/A |
| Speed constant | 433 rpm/V |
| Speed / torque gradient | 8.55 rpm/mNm |
| Mechanical time constant | 7.61 ms |
| Rotor inertia | 85 gcm² |
| Thermal data | |
| Thermal resistance housing-ambient | 3.2 K/W |
| Thermal resistance winding-housing | 1.2 K/W |
| Thermal time constant winding | 16.7 s |
| Thermal time constant motor | 1050 s |
| Ambient temperature | -20...+125 °C |
| Max. winding temperature | +125 °C |
| Mechanical data | |
| Bearing type | ball bearings |
| Max. speed | 18000 rpm |
| Axial play | 0 mm, at radial load < 8 N |
| 0.14 mm, at radial load > 8 N | |
| Max. axial load (dynamic) | 10 N |
| Max. force for press fits (static) | 170 N |
| (static, shaft supported) | 5000 N |
| Max. radial load | 70 N, 5 mm from flange |
| Other specifications | |
| Number of pole pairs | 1 |
| Number of phases | 3 |
| Number of autoclave cycles | 0 |
| Product | |
| Weight | 390 g |
-
Operating Range
| Continuous operation range | ||
| Short term operation range | ||
